Specifications of Tire Plunger And Bead Unseating Tester
Model:LQD-3/4
Motor Power: 5 kW AC
Structure: Vertical Machine Frame
Rim Diameter：12″ ~ 28″
Tire Diameter: Φ 480 ~ Φ1400mm
Tire Section Width: Max.500mm
Loading Method: Mechanical Servo Loading
Plunger Test Load: Max. 100 kN
Bead Unseating Test Load: Max. 20 kN
Test Speed: 50 ± 2.5 mm/min
Plunger Return Speed: 50 ~ 500mm/min
Dimension: Approx. L2600 mm × W1500 mm × H2600mm
Total Weight: Approx. 4.5 t
Application:
Used for passenger car and truck and bus tire plunger and bead unseating test.
Features:
1. Standard: GB/T 15704, ISO 7141, SAE j 175, JIS D 4103, GMW, VIA, JWL-T
2. Operation comfortable
3. Safety
4. Bending moment and oscillation way are shown in polar co-ordination
5. Quick clamping system
6. Good after-sale service

Service for Tire Plunger And Bead Unseating Tester
1. One year warrenty
2. Professional technology team provide one-site training
3. Lifelong maintenance


Packaging for Tire Plunger And Bead Unseating Tester:
shanghai Materials checked each process from the delivery of raw materials up to the packing process to prevent damage and ensure our products always at super quality.
* Capacity: 1 pieces per 20 feet container
