- Specifications of Enameled Aluminum Wire
1) Wire diameter: 0.2mm – 6.5mm
2) Type: enamelled aluminum wire
3) Standard: 60317-12, MW30 60317-8, MW35 60317-13, MW15 60317-12, MW16 60317-46
4) Thermal Class: 120℃ – 300℃
5) Cross section range: 0.1mm – 6.5mm
6) Range of insulation thickness: IEC60317-0-1 GB6108.2-85
7) Enamel base coat:
a) Polyester
b) Modified Polyester
c) Polyester-Imide
d) Polyvinyl fomal Polyimide
8) Heat shock: 155℃ – 300℃
9) MOQ: 100kg – 500kg
10) Payment Terms : L/C acceptable
Features of Enameled Aluminum Wire
1) Excellent bending property
2) High flexibility of the enamel
3) Good resistance to abrasion
4) High mechanical property
5) Higher thermal property
6) Good resistance to refrigerant and freon
7) Suitable for windings that are subjected to constantly high temperature and mechanical stress
8) Good chemical resistance
9) Outstanding mechanical and chemical property
Corona Resistant Enamelled Round Aluminium Wire:
【PRODUCT ITEM】 : Q(ZY/XY)BP-*/220(L)
【THERMAL CLASS】: Φ0.150-5.100mm
【DIAMETER】: IEC 60317-0-3 GB/T 23312.1
【STANDARD】: Delay due to the rapid rise and fall along the pulse dielectric heating caused by insulation aging, improve the interturn insulation life.
【PACKING STANDARD】: Coating mold coating process.
【PRODUCT FEATURE】: The quality of electrician round aluminum rod and Alan Tas insulating paint.
【APPLICATION】: Mainly used in special motor
Self-adhesive line aluminum enamelled round aluminium wire
【PRODUCT ITEM】 : SBEIW/200A,QZY-xB/200(L)
【THERMAL CLASS】:Φ0.150~5.100mm
【DIAMETER】IEC 60317-0-3 GB/T 23312.1
【STANDARD】 : A bond, line in the heating or solvent bonding can.
【PACKING STANDARD】: Coating mold coating process.
【PRODUCT FEATURE】: The quality of electrician round aluminum rod and Alan Tas insulating paint.
【APPLICATION】: Mainly used in electric motor coil
240 grade polyester imide composite polyamide imide enamelled round aluminium wire
【PRODUCT ITEM】 : EI/AIWA-x, Q (ZY/XY) -A-x
【THERMAL CLASS】: Φ 0.150~5.100mm
【DIAMETER】：IEC 60317-0-3 GB/T 23312.1
【STANDARD】 :High temperature resistant enameled wire, with excellent flexibility and adhesion, good thermal performance.
【PACKING STANDARD】:Polyester imide composite high performance polyamide imide coating.
【PRODUCT FEATURE】: The quality of electrician round aluminum rod and Alan Tas insulating paint.
【APPLICATION】: Apply to C and above motor, electrical coil
If you are interested in our Aluminum Products , please submit the webform below with the sizes . We will quote the latest price to you within one business day . Customization and bulk orders are our specialty.
ENAMELED ALUMINUM WIRE Insulated Enameled Aluminum Wire for Transformers
Enamelled aluminum wire is widely used in transform , which products are:240 class composite enamelled aluminum wire, 220 class composite enamelled aluminum wire, 200 class polyesterimide enamelled aluminum wire, 130-180 class polyester and polyurethane enamelled aluminum wire, and we can also produce various types of enamelled round aluminum wire according to the customer’s requirements.
